Common 150A BusBar

Blue Sea System

Common 150A BusBar

2300
Pre Order
RM184.00

Buy Now, Pay Later with

Enjoy flexible payments for up to 24 months. Learn more.

Terminals
Cover
SIZES & DIMENSIONS
WHAT'S IN THE BOX
FEATURES
  • The industry standard busbar for positive distribution
  • The industry standard busbar for the collection of negative or AC ground circuits
SPECIFICATIONS
  • Maximum Voltage: 300V AC, 48V DC
  • Number of Screw Terminals: 10
  • Number of Terminal Studs: 2
  • Terminal Type: 1/4" Stud, #8-32 Screw
  • Continuous Rating : 130A AC, 150A DC
  • Base Material: UL 94-V0 Rated, Glass Reinforced Thermoplastics
  • Bus Material: Tin-Plated Copper CDA 110 / UNS 11000
  • Cover Material: Clear Polycarbonate
  • Screw Terminal Torque: 15 in-lb (1.69 Nm)
  • Stud Torque: 60 in-lb (6.78 Nm)
  • Weight: 0.37lb (0.17 kg)
DOCUMENTATIONS

Dimensioned Drawing
