Haswing

Ventura F 5.0 Brushless Motor

Ventura F 5.0 Brushless Motor

Part Number: 50752-80_B

Pre-Order

RM3,850.00
RM0.00 RM3,850.00
% Off Sold out
Shipping calculated at checkout.
Voltage (Thrust)
Shaft Length

Payment option

Pay now and get your item between 4-6 weeks.
Note: Please contact our sales team for further enquiry and product lead time.

Description & Specification

The Ventura F is equipped with a brushless 5.0/24V motor and is excellent for the propulsion of a wide range of boats and waterways. This powerful motor is equipped with step-less adjustable speed control and a safety lanyard. The motor can easily be tilted in and out of the water, so you can motor in virtually any water. The Ventura F model also features and LED battery level indicator. An additional steering wheel unit is required. Suitable for both salt and fresh water.

SPECIFICATION
Model VENTURA F 5.0
Max Voltage DC 24V
Depth Adjustment Not Available
Max Thrust 6HP
Prop Type 3blade prop / 10.7inch diam
Pro Speed at Full Power: Max. 1450 rpm underwater
Battery Type 2x120AH Deep Cycle
Max Boat Length & Load 8m
Steering Ratio 360 degree control
Power - Max 2520W
Amp - Max 105A
Decivel Level (db) 55db
Mount
Shaft Type Stainless Steel + Aluminium
Shaft Length 800mm

⚠️ IMPORTANT NOTE:
Product dimensions are subject to change without prior notice due to updates in manufacturer safety guidelines and standards. As a result, the size of the product delivered may vary slightly from the specifications provided at the time of order. We recommend reviewing the latest information before purchase to ensure compatibility. This policy is in place to prioritize your safety and the quality of our products.

Product images are for illustration purposes only and may vary based on your monitor’s resolution. Actual colors and details of the product may differ from what is displayed. Please consider this when making your purchase.
