ICOM M73 Plus HAndled Submersible VHF Marine Radio boatyardmalaysia

ICOM

ICOM M73 Plus HAndled Submersible VHF Marine Radio

SKU: M73 PLUS 71 USA
Pre Order
RM2,394.00

Buy Now, Pay Later with

Enjoy flexible payments for up to 24 monthsLearn more.

Slim, Stylish, Powerful VHF with Professional Features

SIZES & DIMENSIONS
  • Dimensions (W×H×D): 52.5 × 125 × 30 mm (2.0 × 4.9 × 1.2 in)
WHAT'S IN THE BOX

ICOM M73 Plus HAndled Submersible VHF Marine Radio

FEATURES

IPX8 Submersible Plus™

The IC-M73 maintains our highest level of waterproof protection, delivering unparalleled durability. This radio has undergone rigorous testing and has proven its ability to survive being submerged in water up to a depth of 1.5 meters (4.9 feet) for 30 minutes.

Slim, Hourglass Body Wide Viewing Angle LCD

The IC-M73 features a sleek and ergonomic design that combines style with functionality. Its durable and rugged body ensures user-friendly operation and a long lifespan. The high-intensity LCD with a wide viewing angle provides bright and easily readable characters, enhancing the overall user experience.

700 mW Loud Audio

The IC-M73 utilizes a BTL (bridge-tied load) amplifier, effectively doubling the audio output for enhanced performance. Its internal speaker produces a powerful 700mW audio output, ensuring clear and loud sound quality.

AquaQuake™ Water Draining Function

The AquaQuake™ prevents audio degradation from a water-logged speaker. This function removes water from the speaker grill by vibrating the speaker cone. You can hear clear audio with this function.

6 W RF Output Power

The IC-M73's 6 Watts of transmit power provides extended communication range for the user. A large capacity Lithium-Ion battery, BP-245H allows for 17 hours of operation, under normal conditions*.

* Typical operation with 5:5:90 duty ratio. 20 hours for basic version.

Dualwatch and Tri-watch function

The Dualwatch and Tri-watch functions allow for periodic checking of Channel 16 while operating on another channel. This feature proves convenient when communicating with your friends' vessels or during sailing regattas, enabling you to make important announcements about the race.

Last Call Voice Recording*

The last call voice recording function automatically saves the last incoming call for 1 minute. You can also start recording manually. You will not miss an important call.

* Available in the IC-M73 PLUS only

Active Noise Cancelling Technology*

The built-in bidirectional active noise cancelling reduces background noise to up to 90% and improves both your transmitted voice and incoming call. You will hear better and clearer!

* Available in the IC-M73 PLUS only

Bass Boost Function*

The signal processing technology emphasizes low-pitched sound to provide a rich bass sound for both transmit and receive signals.

* Available in the IC-M73 PLUS only

Additional features

・    Low Battery Alert function notifies you of low battery level with an alarm
・    Favorite channel and tag scan functions
・    Rapid desktop charger, BC-210, and cigarette lighter cable, CP-25H, are supplied
・    Optional waterproof speaker-microphones, HM-167 and HM-202
・    Auto power save function
・    Supports 4-digit channels
・    Monitor function
・    Lock function
・    Power Save function
・    Backlight function for night time opeartion
・    LCD contrast selection

SPECIFICATIONS

General

  • Frequency range (TX): 156.025–157.425 MHz
  • Frequency range (RX): 156.050–163.275 MHz
  • Usable channel groups: INT, USA, CAN, WX channels
  • Type of emission: 16K0G3E (FM)
  • Current drain:TX (6 W): 1.5 ARX (Max audio, Internal SP / External SP): 450 mA / 250 mA
  • Operating temperature: –20°C to +60°C (–4°F to +140°F)
  • Antenna impedance: 50 Ω
  • Dimensions (W×H×D): 52.5 × 125 × 30 mm (2.0 × 4.9 × 1.2 in)
  • Weight: 320 g (11.3 oz) with BP-245H, FA-S64V, MB-103

Measurements made in accordance with TIA/EIA-603. Specifications subject to change without notice.

Transmitter

  • Output power (Hi/Mid/Low): 6 W / 3 W / 1 W
  • Max. frequency deviation: ±5.0 kHz
  • Frequency stability: ±10 ppm
  • Spurious emissions: –68 dBc typical
  • Adjacent channel power: 70 dB
  • Audio harmonic distortion: 10% (at 60% deviation)
  • Residual modulation: 40 dB

Receiver

  • Sensitivity: 0.22 µV typical (at 12 dB SINAD)
  • Squelch sensitivity: 0.35 µV typical (threshold)
  • Adjacent channel selectivity: 70 dB typical
  • Spurious response: 70 dB typical
  • Intermodulation: 70 dB typical
  • Hum and noise: 40 dB
  • Audio output power (at 10% distortion):Internal speaker: 700 mW typicalExternal speaker: 350 mW typical

MIL-STD-810G Compliance

  • Low pressure (storage/operation): 500.5 I, II
  • High temperature (storage/operation): 501.5 I, II
  • Low temperature (storage/operation): 502.5 I, II
  • Temperature shock: 503.5 I-C
  • Solar radiation: 505.5 I
  • Rain (blowing/drip): 506.5 I, III
  • Humidity: 507.5 II
  • Salt fog: 509.5
  • Dust blowing: 510.5 I
  • Water immersion: 512.5 I
  • Vibration: 514.6 I
  • Shock (functional/transit drop): 516.6 I, IV
  • Also meets MIL-STD-810C, D, E and F

Ingress Protection

  • IPX8 (Waterproof protection)

Supplied Accessories

  • CP-25H cigarette lighter cable
  • BC-123SA/SE AC adapter
  • BC-210 rapid charger
  • BP-245H battery pack
  • MB-103 belt clip
  • FA-S59V or FA-S64V antenna
  • Hand strap
DOCUMENTATIONS

Catalogs / Brochures

Brochures Name

IC-M73PLUS3.06MB

Marine Radios7.14MB

Instruction Manual / Guides

NameModel Name

Instruction ManualIC-M73/IC-M73EURO
