  • STRIKER™ 4 FishFinder W/4-Pin, 77/200kHz TM Transducer
STRIKER™ 4 FishFinder W/4-Pin, 77/200kHz TM Transducer

Garmin

STRIKER™ 4 FishFinder W/4-Pin, 77/200kHz TM Transducer

SKU: 010-01550-10
5 left
RM700.00 RM780.00

Buy Now, Pay Later with

Enjoy flexible payments for up to 24 months. Learn more.

Finding fish is easier than ever with STRIKER 4 fishfinder. Mark and return to your hot spots, boat ramps and docks, and share your favorite waypoints and routes with other STRIKER and echoMAP™ combos. Smooth Scaling™ graphics provide uninterrupted imagery when switching between depth-range scales. Sonar history rewind allows you to scroll back through sonar images to mark waypoints you originally may have missed. Plus, it has a built-in flasher and displays speed data. Includes tilt/swivel mount, CHIRP (77/200 kHz) transducer with transom and trolling motor mounting hardware and cable. For high-performance CHIRP, purchase a GT8 or GT15 transducer (each sold separately).
SIZES & DIMENSIONS
  • Dimensions: 3.6" x 5.9" x 1.6" (91.6 x 150.8 x 42.8 mm)
WHAT'S IN THE BOX
  •    STRIKER 4
  •    Dual-beam transducer
  •    Transom and trolling motor mounts
  •    Tilt/swivel mount
  •    Power cable
  •    Documentation
FEATURES
  • Easy-to-use 3.5-inch color fishfinder with built-in, high-sensitivity GPS
  • Find fish; mark and return to hot spots, docks and ramps
  • Convenient keypad operation
  • Includes CHIRP (77/200 kHz) sonar transducer; transmit power (200 W RMS)/(1,600 W peak-to-peak)
  • Upgrade to high performance CHIRP with a GT8 or GT15 transducer (each sold separately)
SPECIFICATIONS

Specifications (Point Form):

  • Transducer Cable Length: 20 ft
  • Dimensions: 3.6" x 5.9" x 1.6" (91.6 x 150.8 x 42.8 mm)
  • Weight: 0.5 lbs (230 g)
  • Water Rating: IPX7

Display

  • Display Type: HVGA Color
  • Screen Size: 3.5" Diagonal (1.9" x 2.9")
  • Resolution: 480 x 320 pixels

Mounting & Control

  • Mounting Options: Flush, Tilt/Swivel
  • Input Type: Keyed

Maps & Memory

  • Waypoints/Favorites/Locations: 5,000
  • Track Points: 50,000
  • Tracks: 50
  • Navigation Routes: 100

GPS & Sensors

  • Built-in GPS Receiver: Yes
  • Receiver Frequencies: 50/77/200 kHz (Traditional), CHIRP (Mid & High)
  • WAAS Support: Yes

Power & Electrical

  • Power Input: 10–20 VDC
  • Typical Current Draw: 0.23 A
  • Max Current Draw: 1.0 A
  • Power Consumption: 2.8 W

Sonar Features

  • Sonar Display: Yes
  • Traditional Sonar: Built-in (Dual Frequency/Beam)
  • Transmit Power: 200 W (RMS)
  • Bottom Lock: Yes
  • Water Temperature Log: Yes

Connections

  • 4-Pin Transducer Port: 1

Fishfinder Features


Split-Screen Zoom: Yes

  • Fish Symbol ID: Yes
  • AutoGain Technology: Yes
  • Adjustable Depth Line: Yes
  • A-Scope (Real-Time Display): Yes
  • Water Temperature Sensor: Included
  • Depth Range Shading: Yes
DOCUMENTATIONS

Revision ASep 2016190-02160-05

Revision BApr 2016190-01950-91

Revision --Sep 2020

Revision --Jul 2022
